Drum Dryer, Rotary Dryer
The rotary dryers are custom engineered and manufactured to achieve optimum drying efficiency. This rotary drying machine is used for drying wood particles, sawdust, wood chips, disintegrated seasonal annual crops and other biomass. With proven quality and performance, our rotary drum dryer is a good choice to meet your drying needs.
- Model:
SG-10
- Output(ton/h): 1.0-1.5
- Dryer Dimension(L*W*H）(m): 5.8*2.4*2.7
- Installed Power(kW): 29
- Energy Consumption(Kcal/h): 49
- Firewood used(kg/h): 140-175
- Model:
SG-20
- Output(ton/h): 2.0-2.5
- Dryer Dimension(L*W*H）(m): 7*2.6*3.2
- Installed Power(kW): 40
- Energy Consumption(Kcal/h): 98
- Firewood used(kg/h): 345-430
- Model:
SG-30
- Output(ton/h): 3.0-3.5
- Dryer Dimension(L*W*H）(m): 10*2.6*3.3
- Installed Power(kW): 70
- Energy Consumption(Kcal/h): 148
- Firewood used(kg/h): 420-525
- Model:
SG-40
- Output(ton/h): 4.0-4.5
- Dryer Dimension(L*W*H）(m): 10.5*2.9*3.6
- Installed Power(kW): 90
- Energy Consumption(Kcal/h): 196
- Firewood used(kg/h): 600-750
- Model:
SG-50
- Output(ton/h): 5.0-6.0
- Dryer Dimension(L*W*H）(m): 11.6*3.3*3.8
- Installed Power(kW): 140
- Energy Consumption(Kcal/h): 245
- Firewood used(kg/h): 720-900
- Model:
SG-60
- Output(ton/h): 6.0-7.0
- Dryer Dimension(L*W*H）(m): 12*3.5*4.0
- Installed Power(kW): 155-165
- Energy Consumption(Kcal/h): 295
- Firewood used(kg/h): 900-1125
| Model | SG-10 | SG-20 | SG-30 | SG-40 | SG-50 | SG-60 |
| Output(ton/h) | 1.0-1.5 | 2.0-2.5 | 3.0-3.5 | 4.0-4.5 | 5.0-6.0 | 6.0-7.0 |
| Dryer Dimension(L*W*H）(m) | 5.8*2.4*2.7 | 7*2.6*3.2 | 10*2.6*3.3 | 10.5*2.9*3.6 | 11.6*3.3*3.8 | 12*3.5*4.0 |
| Installed Power(kW) | 29 | 40 | 70 | 90 | 140 | 155-165 |
| Energy Consumption(Kcal/h) | 49 | 98 | 148 | 196 | 245 | 295 |
| Firewood used(kg/h) | 140-175 | 345-430 | 420-525 | 600-750 | 720-900 | 900-1125 |
Features of Rotary Dryers
- Featuring high thermal efficiency and low moisture fluctuation, the rotary drum dryer machine is designed according to material characteristics to meet the unique processing needs of your material.
- During the drying process, moisture content can be adjusted according to customer needs.
- The flights in the rotating drum tumble the materials dried, making drying uniform and rapid.
- The material flow in the rotating drum is controlled by a variable frequency drive.
- The exhaust gas features low temperature,
- Designed with a hot air furnace, the drying machinery features high drying efficiency.
- The rotary drum dryer comes with low risk of fire and explosion, and high standard of safety and reliability.
- Proven seal technology ensures minimal air leakage may occur in the drying system.
